Speaker Size | 7.7" |
---|---|
Peak Power | 240 Watts |
RMS Power Rating | 60 Watts |
Efficiency (1W/1M) | 92dB |
Frequency Response | 70 Hz - 18 kHz |
Nominal Impedance | 4 ohms |
Recommended Amplifier Power (RMS) | 25 - 200 W/Ch |
Tweeter Type | Aluminum dome |
Cone / Surround Material | Polypropylene with cloth surround |
Mounting Diameter Clearance | 162mm (6-3/8") |
Mounting Depth Clearance | 77mm (3") |
Optimum Enclosure Volume (Sealed enclosure, fully filled with absorption material) | 10 L |
LED Color Options | RGB |
LED Supply Voltage | 10.8 to 16V dc |
LED Load Current at 14.4V dc | 150mA |
Operating Temperature Range | 0 to 50°C (32 to 122°F) |
Storage Temperature Range | -20 to 70°C (-4 to 158°F) |
Water and Dust Resistance (IP rating) | IP65 |
Speaker Dimensions: Length x Height x Depth | Ø 196mm x 97mm [Ø 7-11/16" x 3-13/16"] |
Warranty | 3 years |
